This document is the user manual for Agilent Technologies' Agilent 35900E Dual Channel Interface. The manual describes the features and characteristics of the product.
This manual provides instructions for setting up and operating the Agilent 35900E dual-channel interface, which converts analog signals from lab instruments into digital data for host computers. It covers hardware connections, including MIO cards for GPIB/RS-232 and TCP/IP, as well as front panel controls and safety guidelines. The device supports independent analog-to-digital conversion and real-time control via remote bus and TTL I/O ports.
It converts analog signals from analytical instruments to digital data and transmits it to the host computer.
It uses Modular Input/Output (MIO) for host communications.
The signals include START, STOP, READY and START REQUEST.
