Key facts
- Brand
- Philips
- Model
- LPC2129
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-05-02
Start here
Philips LPC2119/2129/2194/2292/2294 ARM-based Microcontroller User Manual
This manual introduces the Philips LPC2119/2129/2194/2292/2294 ARM‑based microcontroller family, describing its core architecture, on‑chip flash and SRAM, and the range of integrated peripherals such as UART, I2C, SPI, CAN and timers. It also provides information on system control blocks, power management, PLL, and debugging support via RealMonitor.
The document includes extensive tables and figures covering pin‑outs for the 64‑pin and 144‑pin packages, register maps, memory maps, and configuration options. It serves both developers and engineers who need to design hardware, write firmware, or perform in‑system debugging of these devices.
Philips LPC2129 specifications
| Processor Core | ARM7TDMI‑S |
|---|---|
| Flash Memory Size | 128 kB |
| Package Types | 64‑pin (LPC2119/2129/2194) and 144‑pin (LPC2292/2294) |
| Package Types | 64‑pin (LPC2119/2129/2194) and 144‑pin (LPC2292/2294) |
Source: Philips LPC2119/2129/2194/2292/2294 ARM-based Microcontroller User Manual
All Philips LPC2129 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What processor core does the LPC2119/2129/2194/2292/2294 use?
It uses an ARM7TDMI‑S processor core.
From: Philips LPC2119/2129/2194/2292/2294 ARM-based Microcontroller User Manual
How much flash memory is available on these microcontrollers?
Each device provides 128 kB of on‑chip flash memory.
From: Philips LPC2119/2129/2194/2292/2294 ARM-based Microcontroller User Manual
Can the microcontrollers be used in life‑support equipment?
No, they are not designed for life‑support applications and use is at the customer's own risk.
