Philips ESC 026 Lighting Controller Manual
This manual covers the overall parameters of the ESC 026 lighting controller, including electrical ratings, temperature limits, and physical dimensions. It also provides wiring guidelines and packaging information.
Key data such as operating voltage (220‑240 V, 60 Hz), power consumption (1 W), rated lifetime (57 677 hours), and temperature range (‑30 °C to 75 °C) are listed, along with the device dimensions (100 mm × 81.5 mm × 45.0 mm × 30 mm) and weight (0.060 kg). This manual is written in Chinese.
Philips ESC 02 specifications
| Operating voltage | 220-240 V 60 Hz |
|---|---|
| Rated lifetime | 57677 hours |
| Temperature range | -30 (min), 75 (max) C |
| Dimensions (L × W × H × D) | 100 mm × 81.5 mm × 45.0 mm × 30 mm |
| Weight | 0.060 kg |
All Philips ESC 02 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the operating voltage of the ESC 026?
The ESC 026 operates at 220‑240 V, 60 Hz.
What is the rated lifetime of the controller?
The controller is rated for 57 677 hours of operation.
What is the operating voltage of the ESC 02?
The ESC 02 operates at 220‑240 V, 50 Hz.
How long is the expected lifetime of the ESC 02?
The rated lifetime is 57 677 hours.
