Start here
PHILIPS EB-P 218 PL-T/C ICC 220-240V 50/60Hz Manual
This manual describes the technical specifications of the Philips EB-P 218 PL‑T/C lighting unit, including rated voltage, frequency, power consumption, dimensions and EMI compliance. It also lists connection requirements, temperature limits and safety certifications.
Packaging information, bar‑code data and regulatory markings are provided, along with a brief overview of the product’s physical layout and terminal identification. This manual is written in Chinese.
Philips C ICC 220-240V specifications
| Rated Voltage | 220‑240 V |
|---|---|
| Frequency | 50/60 Hz |
| Dimensions (L×W×H) | 123.0 mm × 111.0 mm × 79.0 mm |
| Weight | 0.094 kg |
| EMI Frequency Range | 9 kHz – 30 MHz |
All Philips C ICC 220-240V documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- PHILIPS EB-P 218 PL-T/C ICC 220-240V 50/60Hz Manual 2 p
- PHILIPS EB-P 226 PL-T/C ICC 220-240V 50/60H Manual 2 p
- PHILIPS PLT/C Lights EBPrimalume Electronic Ballast EB-P 126 PL-T/C ICC 220-240V 50/60Hz Manual 2 p
- PHILIPS PLT/C Lights EBPrimalume Electronic Ballast EB-P 113 PL-T/C ICC 220-240V 50/60Hz user manual 2 p
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the rated voltage of the EB-P 218 PL‑T/C?
The rated voltage is 220‑240 V.
What are the dimensions of the product?
The dimensions are 123 mm × 111 mm × 79 mm.
What is the rated voltage of the EB-P 226 PL‑T/C ICC?
The unit is rated for 220‑240 V.
What are the physical dimensions of the product?
The dimensions are 123 mm × 79 mm × 33 mm.
What is the input voltage range for the EB‑P 118 PL/T/C ICC ballast?
The ballast operates from 220 V to 240 V AC.
From: Philips EB-P 118 PL/T/C ICC 220-240V 50/60Hz Electronic Ballast Manual
What is the power factor of the ballast?
The power factor is 0.95.
From: Philips EB-P 118 PL/T/C ICC 220-240V 50/60Hz Electronic Ballast Manual
