Key facts
- Brand
- Analog Devices
- Model
- ADXL001
- Category
- sensor
- Industry
- Electronics
- Documents
- 2
- Languages
- ZH · EN
- Last added
- 2022-09-13
Start here
Analog Devices MEMS Accelerometer Sensor FAQ
This document serves as a Frequently Asked Questions (FAQ) guide for Analog Devices' MEMS accelerometer sensor products. It provides an introduction to the product line, including iMEMS and iSensor devices, and details their selection criteria based on performance metrics.
The guide explains the underlying operating principles of accelerometers using mass-spring models and capacitive sensing. Furthermore, it defines key technical parameters such as measurement range, sensitivity, noise density, nonlinearity, and alignment errors to assist users in understanding sensor behavior. This manual is written in Chinese.
All Analog Devices ADXL001 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the voltage supply range for the ADXL345 accelerometer?
The ADXL345 requires a voltage supply between 2.0 and 3.6 V.
What supply voltage range does the ADXL001 support?
The ADXL001 can operate on voltage supplies from 3.3 V to 5 V.
How low is the noise performance of the ADXL001?
It achieves low noise of 4 mg/V·Hz, with a measured noise of 85 mg rms over 10 Hz‑400 Hz.
