Key facts
- Manuals
- 42
- Models
- 1
- Brands
- 1
- Languages
- ZH · EN · JA · SV
- Last added
- 2026-10-01
sensor models by brand
Featured sensor manuals
Juying Aoxiang JYS-YX-K-01 Rain/Snow Sensor User Manual
The JYS-YX-K-01 rain/snow sensor measures precipitation in outdoor environments such as greenhouses, farms, and buildings. It offers wide voltage supply, RS485 Modbus communication, automatic heating, and adjustable sensitivity, all housed in an IP68‑rated enclosure.
The manual provides product overview, main technical parameters, RS485 wiring instructions, Modbus register details, software setup, configuration of device address and baud rate, installation dimensions, troubleshooting tips, and technical support contacts. This manual is written in Chinese.
Covers: Product Introduction · Main Parameters · Interface Description · Communication Wiring · Development Materials · Test Software
SDE-18 User Manual
This manual describes the SDE-18 data acquisition device, covering its hardware overview, technical parameters, and key features. It includes detailed sections on device configuration, RS232 communication, GPS data output, and power settings.
The document also provides tables of measurement ranges, frequency specifications, and example data strings, helping users to correctly install, calibrate, and operate the SDE-18 in field applications. This manual is written in Chinese.
Covers: Device Overview · Technical Parameters · Device Features · Data Acquisition · RS232 Data Format · GPS Data Format
ASAIR AHT15 Humidity and Temperature Sensor Datasheet
The AHT15 is a fully calibrated digital humidity and temperature sensor with a compact package and PTFE‑protected housing for harsh environments. It offers a supply range of 1.8‑3.6 V (recommended 3.3 V) and operates from –40 °C to 80 °C with a humidity range of 0‑80 %RH.
The document includes performance tables, electrical characteristics, pin definitions, wiring recommendations, and detailed instructions for soldering, storage, recovery, and signal integrity. It also describes the I2C command set, timing diagrams, and packaging information for mass production. This manual is written in Chinese.
Covers: 产品综述 · 传感器性能 · 电气特性 · 包装信息 · 应用信息 · 存储条件和操作说明
Lvqing QZX327 Human Micro‑Motion Sensor User Manual
The QZX327 human micro‑motion sensor uses ultra‑wideband radar and biomedical engineering to detect body presence, breathing and subtle movements. It is suited for smart toilets, robots, offices, conference rooms, restrooms and hospitals.
The manual details electrical parameters, communication settings, device functions, installation, wiring, remote‑control adjustments and safety precautions for reliable operation. This manual is written in Chinese.
Covers: Product Overview · Electrical Parameters · Communication Parameters · Device Functions · Installation and Wiring · Remote‑Control Settings
Latest sensor manuals
Juying Aoxiang JYS-YX-K-01 Rain/Snow Sensor User Manual
User Manual 15 pages · 765 KB · ZHUser manual for the JYS-YX-K-01 rain/snow sensor by Juying Aoxiang, covering features, wiring, Modbus communication and configuration.
SDE-18 User Manual
User Manual 22 pages · 1.2 MB · ZHThe SDE-18 User Manual provides setup, data acquisition, configuration, and operation instructions for the SDE-18 device.
ASAIR AHT15 Humidity and Temperature Sensor Datasheet
Datasheet 9 pages · 1004 KB · ZHThe ASAIR AHT15 sensor datasheet provides specifications, electrical characteristics, pinout, I2C communication details, and application guidelines.
Lvqing QZX327 Human Micro‑Motion Sensor User Manual
User Manual 8 pages · 613 KB · ZHThe Lvqing QZX327 sensor detects tiny human motions using ultra‑wideband radar and provides RS485 output for smart devices.
TONYU DY-PT204-6B Infrared Receiver Specification
Datasheet 8 pages · 445 KB · ZHThe TONYU DY-PT204-6B infrared receiver specification details its features, electrical parameters, packaging, and handling guidelines.
CASSY Hysteresis Lab Manual
Other 12 pages · 275 KB · ENLab manual for the CASSY Hysteresis experiment covering aims, equipment, setup, and measurement procedures.
Dynamax ASN308301 Temperature & Humidity Detector User Manual
User Manual 2 pages · 2.5 MB · ENThe Dynamax ASN308301 Temperature & Humidity Detector User Manual provides installation, operation, specifications, and warranty information.
Autionics BTF Series Thin Optical Sensor Datasheet
Datasheet 3 pages · 2.8 MB · ZHTechnical data sheet for Autionics BTF series ultra‑thin optical sensors with IP67 protection and 12‑24 VDC operation.
NXP SA56004X sensor
The NXP Semiconductors SA56004X is an SMBus compatible, 11-bit remote/local digital temperature sensor with overtemperature alarms. The remote channel of the SA56004X monitors a diode junction, such as a substrate PNP of a microprocessor or a diode connected transistor such as the 2N3904 (NPN) or 2N3906 (PNP). With factory trimming, remote sensor accuracy of 1 C is achieved.
NXP PCA8885 sensor
PCA8885 is an 8-channel touch sensor chip produced by NXP. It uses EDISEN technology to automatically compensate for static capacitance changes
NXP PCF8885 sensor
The integrated circuit PCF8885 is a capacitive 8-channel touch and proximity sensor that uses a patented (EDISEN) method to detect a change in capacitance on remote sensing plates. Changes in the static capacitances (as opposed to dynamic capacitance changes) are automatically compensated using continuous auto-calibration. Remote sensing plates (for example, conductive foils) can be connected to the IC1 using coaxial cable. The eight input channels operate independently of each other. There is a
NXP PCF8883 sensor
The integrated circuit PCF8883 is a capacitive touch and proximity switch that uses a patented (EDISEN) digital method to detect a change in capacitance on a remote sensing plate. Changes in the static capacitance (as opposed to dynamic capacitance changes) are automatically compensated using continuous auto-calibration. Remote sensing plates (e.g. conductive foil) can be connected directly to the IC1 or remotely using a coaxial cable.
NXP PCT2075 sensor
The PCT2075 also includes an open-drain output (OS) which becomes active when the temperature exceeds the programmed limits. The OS output operates in either of two selectable modes: OS comparator mode or OS interrupt mode. Its active state can be selected as either HIGH or LOW. The fault queue that defines the number of consecutive faults in order to activate the OS output is programmable as well as the set-point limits.
NXP PCA8886 sensor
This datasheet introduces the basic information of NXP PCA8886 sensor. It is a low power dual channel capacitive proximity switch that uses a patented EDISEN digital method to detect a change in capacitance on remote sensing plates. Static capacitance (i.e. non-dynamic capacitance changes) are automatically compensated by continuous auto-calibration. Remote sensing plates (e.g. conductive foil) can be connected directly to the IC1 or remotely using a coaxial cable.
NXP KMZ60 sensor
The KMZ60 angle sensor is dedicated for rotor position detection for BLDC motors.Beyond that the KMZ60 is applicable for Electronic Power Steering (EPS) applications,steering angle measurement, window wiper position detection and general contactless angular measurement (e.g. throttle valves or actuators). The KMZ60 is fully automotive qualified as well as applicable for industrial and consumer applications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in sensor manuals
What is the sensor’s operating temperature range?
The sensor operates from –40 °C to +60 °C.
From: Juying Aoxiang JYS-YX-K-01 Rain/Snow Sensor User Manual
What is the RS232 data format used by the SDE-18?
The RS232 data consists of identifiers such as DT, DTE, and data fields separated by commas, ending with CR/LF.
From: SDE-18 User Manual
What is the operating frequency of the SDE-18?
The device operates at 200 kHz.
From: SDE-18 User Manual
What is the supply voltage range for the AHT15 sensor?
The sensor operates from 1.8 V to 3.6 V, with a recommended voltage of 3.3 V.
What humidity range can the AHT15 measure?
It measures humidity from 0 %RH up to 80 %RH (accuracy may drift above 80 %RH).
How do I adjust the sensor's sensitivity?
Press the sensitivity key, then press a number 1‑9; level 1 is least sensitive, level 9 is most sensitive (default 9).
