This document provides the operation manual for CS1W-ETN01 (10Base-5), CS1W-ETN11 (10Base-T), and CJ1W-ETN11 (10Base-T) Ethernet Units. It includes information on the product features and precautions for use.
This manual describes the installation, configuration and operation of the SYSMAC CS‑series CS1W‑ETN01 (10Base‑5), CS1W‑ETN11 (10Base‑T) and CJ‑series CJ1W‑ETN11 (10Base‑T) Ethernet Units. It provides detailed procedures for hardware setup, network parameters, IP address configuration, and the use of communication functions such as FINS, socket services, FTP server and mail.
The document also includes safety precautions, system‑setup memory allocations, testing methods, and a comprehensive troubleshooting guide. Technical specifications for each model are listed, including electrical requirements, dimensions, and environmental limits, to help users ensure proper integration into industrial automation systems. This manual is written in Chinese.
| Type | 10Base‑5 (CS1W‑ETN01) / 10Base‑T (CS1W‑ETN11, CJ1W‑ETN11) |
|---|---|
| Baud rate | 10 Mbps |
| Transmission media | Coaxial cable (10Base‑5) / Unshielded twisted‑pair (UTP) cable (10Base‑T) |
| Maximum segment length | 500 m (10Base‑5) / 100 m (10Base‑T) |
| External power supply | 0.3 A min. at 24 VDC (per node) |
| Operating temperature | 0 °C to 55 °C |
The Ethernet Units operate at a baud rate of 10 Mbps.
The CS1W‑ETN01 (10Base‑5) uses coaxial cable for transmission.
Up to four units can be mounted in a CPU rack or expansion rack.
A power supply providing at least 0.3 A at 24 VDC per node is recommended.
