Analog Devices ADSP-21262 EZ-KIT Lite Evaluation System Manual
The document serves as a comprehensive user guide for the ADSP-21262 EZ-KIT Lite evaluation system. It covers package contents, PC configuration requirements, and step-by-step installation procedures for both VisualDSP++ software and the necessary USB drivers for Windows 98, 2000, and XP.
The manual details how to use the hardware features of the board, including external memory, analog and digital audio interfaces, LEDs, and push buttons. It also provides a detailed hardware reference section describing system architecture, connector specifications (such as SPI, DAI, and JTAG), DIP switch settings, and power supply requirements.
Analog Devices ADSP-21262 specifications
| LCD Module | Optrex DMC-16128 |
|---|---|
| LCD Driver | Hitachi HD44780-compatible |
| DSP Model | ADSP-21262 SHARC |
| Development Suite | VisualDSP++ version 3.0 |
| Interface Type | 8-bit interface |
Source: Connecting Character LCD Panels to ADSP-21262 SHARC DSPs Application Note
All Analog Devices ADSP-21262 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
- Connecting Character LCD Panels to ADSP-21262 SHARC DSPs Application Note 11 p
- Analog Devices ADSP-21262 SHARC DSP Engineer-to-Engineer Note 5 p
- Analog Devices ADSP-21262 Interfacing to High-Speed Converter Evaluation Boards 8 p
- Analog Devices ADSP-21262 Porting PC-Based MP3 Player Software Manual 7 p
- Analog Devices EE-295 Implementing Delay Lines on SHARC Processors 7 p
Questions answered in these manuals
How are the LCD control signals connected to the ADSP-21262?
Each of the 11 control pins for the HD44780 driver is connected to a unique programmable flag pin on the DSP.
From: Connecting Character LCD Panels to ADSP-21262 SHARC DSPs Application Note
What is used to control the contrast of the LCD?
A variable potentiometer connected to the Vee pin is used to control the contrast.
From: Connecting Character LCD Panels to ADSP-21262 SHARC DSPs Application Note
What is the maximum instruction rate of the ADSP-21262 core?
The ADSP-21262 core runs at a maximum instruction rate of 200MHz.
From: Analog Devices ADSP-21262 SHARC DSP Engineer-to-Engineer Note
What is the required core voltage for the ADSP-21262?
The ADSP-21262 requires a core voltage of 1.2V.
From: Analog Devices ADSP-21262 SHARC DSP Engineer-to-Engineer Note
What development environment was used for this project?
The project was implemented using the VisualDSP++ 3.0 SP1 development environment.
From: Analog Devices ADSP-21262 Interfacing to High-Speed Converter Evaluation Boards
What is the primary advantage of using a general-purpose DSP over ASICs or FPGAs?
General-purpose DSP solutions typically cost less and have much shorter design cycles, allowing for faster time to market.
From: Analog Devices ADSP-21262 Interfacing to High-Speed Converter Evaluation Boards
