Analog Devices ADA4571R-EBZ Evaluation Board User Guide
The ADA4571R-EBZ evaluation system includes a motherboard, daughterboard, magnetic excitation, SDP interface board, and evaluation software to test and evaluate the performance of the ADA4571 device. The motherboard integrates a 5V regulator, a dual-channel synchronous sampling ADC, and jumpers to enable temperature compensation and shutdown mode. The daughterboard features the ADA4571 device mounted on magnetic excitation with test points for its three outputs.
The guide provides instructions on installing the Windows GUI and SDP drivers, configuring jumpers on the motherboard, monitoring DUT outputs, and using the software interface. It details how to power the system using an external desktop power supply for optimal performance and explains the data acquisition process using the AD7866 ADC. This manual is written in Chinese.
Analog Devices ADA4571 specifications
| Angle Measurement Range | 0 to 180 Degrees |
|---|---|
| Supply Voltage | 2.7 V to 5.5 V |
| Quiescent Supply Current (PD=GND, GC=GND) | 3.5 to 6.5 mA |
| Output Noise | 500 µV rms |
| Output Series Resistance | 60 Ω |
| Output -3 dB Cutoff Frequency | 100 kHz |
Source: Analog Devices ADA4571 Integrated AMR Angle Sensor and Signal Conditioner Data Sheet
All Analog Devices ADA4571 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the temperature range for the ADA4571?
The device operates from −40°C to +150°C.
From: Analog Devices ADA4571 Integrated AMR Angle Sensor and Signal Conditioner Data Sheet
Is the ADA4571 qualified for automotive applications?
Yes, it is qualified for automotive applications.
From: Analog Devices ADA4571 Integrated AMR Angle Sensor and Signal Conditioner Data Sheet
