Key facts
- Brand
- Agilent
- Model
- 7696A
- Documents
- 19
- Languages
- ES · FR · EN · DE · IT · ZH
- Last added
- 2012-07-09
Start here
Agilent 7696A Sample Prep WorkBench Quick Start Manual
The Agilent 7696A Sample Prep Workbench is a system designed to automate sample preparation steps such as dispensing, shaking, mixing, heating, and rotating. It consists of specific hardware modules connected by the Easy Sample Prep and Easy Sequence software technology.
This document serves as a quick start guide for users new to the system. It provides an overview of the WorkBench components, explains how to add instruments using the Setup Wizard, and describes basic operations like defining samples in the Easy Sequence editor and monitoring device status. This manual is written in German.
Agilent 7696A specifications
| Vial Capacity | 150 vials of 2 ml |
|---|---|
| Heating Range (Single Position) | 25 °C to 80 °C |
| Simultaneous Heating/Cooling Capacity | Two trays of 50 vials each |
| Cooling Range (Second Tray) | 40 °C to 5 °C |
Source: Agilent Workbench 7696A Sample Prep WorkBench Brochure Guide
All Agilent 7696A documents by type
How to use the product for one specific task, with worked examples.
- Agilent 7696A Sample Prep WorkBench Serial Dilution Application Note 4 p
- Agilent 7696A Sample Prep WorkBench Automated Clean-up Application Note 6 p
- Agilent 7696A Sample Prep WorkBench Automated PCB Clean-up Application Note 6 p
- Agilent 7696A Sample Prep WorkBench Batch Processing Application Note 4 p
- Agilent 7696A Sample Prep WorkBench FAME Determination Application Note 4 p
Mounting, wiring and first power-up. Read it before the hardware goes in.
Disassembly, diagnostics and part numbers, for repair.
The shortest path to a working setup, usually only a few pages.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What applications is the Agilent Workbench 7696A suitable for?
It is suitable for HPLC, GC, LC/MS, and GC/MS applications.
From: Agilent Workbench 7696A Sample Prep WorkBench Brochure Guide
What type of vials are used for the prepared samples?
All prepared samples end in 2 ml vials compatible with most automatic injectors.
From: Agilent Workbench 7696A Sample Prep WorkBench Brochure Guide
How many vials can the system hold?
The system has a capacity for 150 vials of 2 ml.
What is the temperature range for the heating station?
The heating station operates between 25 °C and 80 °C.
Is the Agilent 7696A compatible with specific vendors?
It is a standalone instrument compatible with any vendor's LC, GC, LC/MS, and GC/MS systems.
What vial types does the system support?
The system supports neckless (shell) vials, standard 2 mL vials, and micro vial inserts.
