Key facts
- Brand
- Agilent
- Model
- 4100 ExoScan
- Category
- Other
- Industry
- Industrial
- Documents
- 9
- Languages
- ZH · PT · EN
- Last added
- 2026-10-23
Start here
Agilent 4100 ExoScan FTIR Spectrometer User Manual
The Agilent 4100 ExoScan is a portable, battery‑operated FTIR spectrometer designed for on‑site analysis of solid and liquid samples. It includes a rugged, water‑resistant enclosure, a built‑in battery for up to four hours of use, and optional AC power for extended operation.
The manual covers unpacking, power connection, instrument startup, software initialization, sample handling with external reflectance and ATR accessories, routine maintenance, spare‑part replacement, and technical specifications such as dimensions, weight, environmental limits and electromagnetic compliance. This manual is written in Portuguese.
Agilent 4100 ExoScan specifications
| Weight (with data system and battery) | 3.2 kg |
|---|---|
| Interferometer Type | Michelson Interferometer |
| Spectral Range | 4000–650 cm-1 |
| Detector Type | Constant Temperature DTGS |
| Battery Capacity (Analyzer) | 4400 mAh Li-ion |
| Operating Temperature | 0 to 50 °C |
Source: Agilent 4100 ExoScan FTIR Spectrometer Product Brochure
All Agilent 4100 ExoScan documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
How to use the product for one specific task, with worked examples.
- Agilent 4100 ExoScan FTIR Application Note: Epoxy Primer Thickness Measurement 4 p
- Agilent 4100 ExoScan FTIR Application Note 6 p
- Agilent 4100/4200 FTIR Composite Thermal Damage Correlation Application Note 4 p
- Agilent 4100 ExoScan FTIR Application Note: Detection of Trace Contamination on Metal Surfaces 6 p
- Agilent 4100 ExoScan FTIR Application Note for O-Ring Identification 4 p
Questions answered in these manuals
What is the weight of the 4100 ExoScan including the data system?
The total weight, including the data system and battery, is only 3.2 kg.
From: Agilent 4100 ExoScan FTIR Spectrometer Product Brochure
How long does the rechargeable lithium battery last?
The powerful rechargeable lithium-ion battery can operate for more than three hours.
From: Agilent 4100 ExoScan FTIR Spectrometer Product Brochure
What is the operating temperature range of the 4100 ExoScan?
The instrument can operate safely from 0 °C up to 50 °C.
How long can the built‑in battery power the FTIR spectrometer?
The battery provides up to four hours of continuous operation.
What types of samples can the Agilent 4100 ExoScan analyze?
It is used for analyzing compounds, coatings, paints, polymers, liquids, solids, and gels.
From: Agilent 4100 ExoScan FTIR Spectrometer Product Brochure
Can the analyzer be used in a laboratory setting?
Yes, it can be mounted on a docking station to be used in the lab just like a benchtop FTIR.
From: Agilent 4100 ExoScan FTIR Spectrometer Product Brochure
