This document describes the performance and reference data of IıR3G O B-337 and IıR3G O B-338 G3R-I/O I/O solid state relays, including action time, reset time, response frequency, etc. It also provides information on wiring sockets and input/output modules.
The handbook details the G3R‑D/I/O solid‑state relay series, including input and output module types, electrical ratings, and performance characteristics. It lists the various model numbers such as G3R‑IAZR1SN, G3R‑IDZR1SN, and G3R‑OA202SZN with their respective voltage and current specifications.
Environmental specifications, such as operating temperature, humidity range, vibration, and shock resistance, are also provided along with mechanical data like weight and insulation resistance. General precautions and reference data for load current versus temperature are included for proper application. This manual is written in Chinese.
| Input voltage (AC) | 100‑240 V |
|---|---|
| Maximum load current (G3R‑OD201SN) | 0.01‑1.5 A |
| Insulation resistance (input‑output) | >100 MΩ |
The AC input voltage range is 100 to 240 V.
The maximum load current is 0.01 to 1.5 A.
The insulation resistance is greater than 100 MΩ.
