Key facts
- Brand
- Texas Instruments
- Model
- A78M00
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-12
Start here
Texas Instruments A78M00 Series Positive-Voltage Regulators Data Sheet
The document describes the UA78M00 series of fixed-voltage integrated-circuit voltage regulators designed for a wide range of applications. These devices can deliver up to 500 mA of output current and feature internal short-circuit current limiting, thermal-overload protection, and safe-area compensation for the output transistor.
Read onlineAll Texas Instruments A78M00 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Are the A78M10 and A78M15 models still available?
No, these specific models are obsolete and no longer supplied.
From: Texas Instruments A78M00 Series Positive-Voltage Regulators Data Sheet
What is the maximum output current for this series?
Each regulator in the series can deliver up to 500 mA of output current.
From: Texas Instruments A78M00 Series Positive-Voltage Regulators Data Sheet
What is the maximum output current of the LLA78M00 regulators?
The regulators can deliver up to 500 mA of output current.
From: Texas Instruments LLA78M00 Series Positive-Voltage Regulator Datasheet
What is the dropout voltage of these regulators?
The dropout voltage is specified as 2 V.
From: Texas Instruments LLA78M00 Series Positive-Voltage Regulator Datasheet
