Maxim MAX3785 6.25Gbps 1.8V PC Board Equalizer Datasheet
The MAX3785 is a 6.25 Gbps, 1.8 V PC board equalizer designed for FR‑4 transmission lines. It combines an equalizer, limiting amplifier, and output driver, and works with both 8b/10b and scrambled data streams. The device operates from a single 1.8 V supply and supports legacy rates from 1.0 Gbps up to 6.4 Gbps.
The datasheet provides absolute maximum ratings, electrical characteristics, typical operating curves, and package information. It is offered in UCSP, WLP, and TDFN‑EP packages, with detailed pin descriptions and ordering tables. Revision history and contact information are also included.
Maxim 25GBPS specifications
| Supply Voltage (Vcc) | +4.75 V to +5.25 V |
|---|---|
| Rise Time | <250 ps |
| Operating Temperature Range | -40 °C to +85 °C |
Source: MAXIM MAX3261 Single +5V Fully Integrated 1.25Gbps Laser Diode Driver Manual
All Maxim 25GBPS documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the supply voltage range for the MAX3785?
The device can be powered from -0.5 V up to +6.0 V, with normal operation at 1.8 V.
From: Maxim MAX3785 6.25Gbps 1.8V PC Board Equalizer Datasheet
What supply voltage range does the MAX3261 require?
The device operates from +4.75 V to +5.25 V supply voltage.
From: MAXIM MAX3261 Single +5V Fully Integrated 1.25Gbps Laser Diode Driver Manual
How many external components are needed for the automatic power control (APC) function?
Only two external components are required to implement the APC function.
From: MAXIM MAX3261 Single +5V Fully Integrated 1.25Gbps Laser Diode Driver Manual
