Start here
Omron A6TN Switch Manual
This manual describes the A6TN series toggle switches, including the blade‑type high‑voltage contact mechanism, environmental ratings, electrical performance, and ordering information. It lists the rated voltage, current, insulation and contact resistance, as well as vibration, shock and life specifications.
The document also contains installation guidance, internal connection diagrams, and dimensional data for each pole configuration, helping users correctly mount and connect the switches in their applications. This manual is written in Chinese.
Omron A6T specifications
| Switching capacity | 25 mA at 24 VDC |
|---|---|
| Insulation resistance | 100 MQ min. |
| Contact resistance | 200 mQ max. |
| Dielectric strength | 500 VAC for 1 min |
| Life expectancy (Mechanical) | 1,000 operations min. |
| Operating temperature | -20°C to 70°C |
All Omron A6T documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum soldering temperature for these switches?
The maximum soldering temperature is 350°C at the tip of the soldering iron.
Can washable models be cleaned with water?
No, do not apply any other solvents or water to clean any washable model because they may deteriorate the materials.
What is the pitch of the Omron A6TR DIP switch?
The switch has a standard pitch of 2.54 mm.
What is the contact resistance of the A6TR switch?
The initial contact resistance is 200 mΩ or less.
What is the rated voltage and current of the Omron A6TN switch?
The switch is rated at DC24 V with a maximum current of 25 mA.
From: Omron A6TN Switch Manual
What temperature range can the A6TN switch operate in?
It can operate from –30 °C to +85 °C.
From: Omron A6TN Switch Manual
