Key facts
- Brand
- Maxim
- Model
- MAX2335
- Industry
- Industrial
- Documents
- 4
- Languages
- EN
- Last added
- 2012-05-07
Start here
Maxim MAX2335 Evaluation Kit User Manual
This document describes the Maxim MAX2335 evaluation kit, which simplifies evaluation of the 450 MHz CDMA/OFDM LNA/mixer. It includes the kit’s features, component list, and ordering information, as well as recommended test equipment.
The manual guides users through quick‑start steps, detailed connections and setup for both the low‑noise amplifier and downconverter modes, and provides board layout considerations. Figures illustrate the schematic and PCB layout of the kit.
Maxim MAX2335 specifications
| LNA Noise Figure | 1.5 dB |
|---|---|
| LNA Gain | 16 dB |
| Operating Temperature Range | -40 °C to +85 °C |
| RF Frequency Range | 420 MHz to 470 MHz |
Source: Maxim Integrated MAX2335 RF Front-End Receiver IC Datasheet
All Maxim MAX2335 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the operating temperature range of the MAX2335?
The device is specified to operate from –40 °C up to +85 °C.
From: Maxim Integrated MAX2335 RF Front-End Receiver IC Datasheet
What is the LNA noise figure of the MAX2335?
The low‑noise amplifier has a typical noise figure of 1.5 dB.
From: Maxim Integrated MAX2335 RF Front-End Receiver IC Datasheet
What is the package type of the MAX2335?
It is available in a 28‑pin thin QFN (TQFN) package with an exposed paddle.
What supply voltage range should be used for the MAX2335?
The recommended VCC range is +2.9 V to +3.3 V.
What supply voltage does the MAX2335 evaluation kit require?
It operates from +2.9 V to +3.3 V with a single‑supply configuration.
How many SMA connectors are included on the kit?
The kit provides 50 SMA connectors for all RF and IF input and output signals.
