Key facts
- Brand
- Maxim
- Model
- MAX5038
- Category
- Power Management
- Documents
- 2
- Languages
- EN
- Last added
- 2012-04-05
Start here
Maxim MAX5038A/MAX5041A Dual‑Phase PWM Controller Datasheet
The MAX5038A and MAX5041A are dual‑phase, average‑current‑mode PWM controllers designed for high‑output‑current applications such as servers, workstations, and high‑density DC‑DC regulators. They operate from either a +4.75 V to +5.5 V or +8 V to +28 V input range and support up to 60 A output current.
The document provides electrical characteristics, absolute maximum ratings, pin configuration, package information, and PCB layout recommendations to help designers implement the controllers in compact, high‑efficiency power supplies.
Maxim MAX5038 specifications
| Input Voltage Range | +4.75 V to +5.5 V or +8 V to +28 V |
|---|---|
| Maximum Output Current | Up to 60 A |
| Switching Frequency per Phase | 250 kHz or 500 kHz (up to 1 MHz for two phases) |
| Package Type | 28‑Pin SSOP |
| Operating Temperature Range | -40 °C to +85 °C |
Source: Maxim MAX5038A/MAX5041A Dual‑Phase PWM Controller Datasheet
All Maxim MAX5038 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What input voltage ranges does the MAX5038A/MAX5041A support?
The controllers accept either a +4.75 V to +5.5 V range or a +8 V to +28 V range.
From: Maxim MAX5038A/MAX5041A Dual‑Phase PWM Controller Datasheet
What is the maximum output current capability?
Both devices can deliver up to 60 A of output current.
From: Maxim MAX5038A/MAX5041A Dual‑Phase PWM Controller Datasheet
What input voltage ranges does the MAX5038 support?
The MAX5038 operates from +4.75 V to +5.5 V or from +8 V to +28 V.
From: Maxim MAX5038/MAX5041 Dual-Phase PWM Controller Datasheet
What is the maximum output current of the MAX5038/MAX5041?
Both devices can deliver up to 60 A of output current.
From: Maxim MAX5038/MAX5041 Dual-Phase PWM Controller Datasheet
