Start here
Maxim MAX220-MAX249 RS-232 Line Drivers/Receivers Datasheet
The MAX220‑MAX249 family provides +5 V‑powered multichannel RS‑232 line drivers and receivers designed for low‑power, battery‑operated systems where +12 V is unavailable. Applications include portable computers, low‑power modems, interface translation, and multidrop RS‑232 networks.
The datasheet lists absolute maximum ratings, detailed electrical characteristics, and a wide range of package options (DIP, SO, SSOP, QFP, etc.). Ordering information, selection tables, and typical operating curves help designers choose the appropriate part and configure it for low‑power shutdown, high‑speed data rates up to 1 Mbps, and various temperature ranges.
Maxim MAX220-MAX249 specifications
| Supply Voltage Range | -0.3 V to +6 V |
|---|---|
| Maximum Data Rate | 1 Mbps |
| Shutdown Power Dissipation | < 5 µW |
| Operating Temperature Range (Typical) | -40 °C to +85 °C |
| Shutdown Supply Current | ≤ 5 µW (typical) |
Source: Maxim MAX220-MAX249 RS-232 Line Drivers/Receivers Datasheet
All Maxim MAX220-MAX249 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum data rate supported by the MAX220‑MAX249 family?
The devices support data rates up to 1 Mbps.
From: Maxim MAX220-MAX249 RS-232 Line Drivers/Receivers Datasheet
How much power does the shutdown mode consume?
Shutdown mode reduces power dissipation to less than 5 µW.
From: Maxim MAX220-MAX249 RS-232 Line Drivers/Receivers Datasheet
What is the supply voltage range for the MAX220‑MAX249 devices?
The devices operate from 0.3 V up to +6 V supply voltage.
What is the maximum data rate supported by these RS‑232 drivers?
They support data rates up to 200 kbps.
