Start here
Analog Devices ADSP-BF535 EZ-KIT Lite Evaluation System User Manual
The ADSP-BF535 EZ-KIT Lite is an evaluation board designed to test the capabilities of the Blackfin embedded media processors. It supports the VisualDSP++ development environment, allowing users to create, compile, and debug application programs written in C++, C, or assembly language. The system connects to a personal computer via USB or JTAG emulation ports for memory access and debugging.
Read onlineAnalog Devices ADSP-BF535 specifications
| Camera Output Format | differential video signals (YUV) 4:2:2, 16-bit wide |
|---|---|
| Camera Clock Frequency | 8.867MHz (PCLK) |
| Processor Internal Memory | 256kBytes of internal L2 Memory |
| CIF Frame Size | 352 X 288 pixels |
Source: Analog Devices EE-181 Interfacing ADSP-BF535 to OV6630 Camera
All Analog Devices ADSP-BF535 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
- Analog Devices EE-181 Interfacing ADSP-BF535 to OV6630 Camera 10 p
- Analog Devices EE-214 Ethernet Network Interface for ADSP-BF535 Blackfin Processors 4 p
- Analog Devices ADSP-BF535 Blackfin Processor PCI Interface Host Mode Application Note 6 p
- Analog Devices ADSP-BF535 Blackfin Processor PCI Interface Device Mode Application Note 9 p
- Analog Devices ADSP-BF535 Blackfin Processor PCI Interface Performance Application Note 5 p
- ANALOG DEVICES Interfacing the ADSP-BF535/ADSP-BF533 Blackfin Processor to NTSC/PAL video decoder over the asynchronous port. Manual 12 p
- Analog Devices ADSP-BF535 Blackfin EZ-KIT Lite CompactFlash Interface Application Note 15 p
- Analog Devices Blackfin Processor Interrupt-Driven Systems Application Note EE-192 9 p
- Analog Devices EE-184 Interfacing EPSON S1D13806 to Blackfin Processors 13 p
- Analog Devices EE-162 Interfacing ADSP-BF535 to High-Speed Converters 24 p
Questions answered in these manuals
How is the OV6630 clocked for data transfer?
The 8.867 MHz PCLK of the OV6630 clocks a 74HC74 configured as a /2 divider to produce a 4.43 MHz output.
From: Analog Devices EE-181 Interfacing ADSP-BF535 to OV6630 Camera
How is blanking data handled to prevent memory overflow?
An AND gate controlled by the HREF signal stops data transfer during blanking periods, ensuring only active video data is stored.
From: Analog Devices EE-181 Interfacing ADSP-BF535 to OV6630 Camera
Which Ethernet controller chip is selected for this interface example?
The SMSC LAN91C111 is selected for the example because it can offload tasks like data buffering, memory allocation, and CRC calculation.
From: Analog Devices EE-214 Ethernet Network Interface for ADSP-BF535 Blackfin Processors
Is an external arbiter required for Host mode?
Yes, an external PCI bus arbiter is required because PCI bus arbitration is not built into the ADSP-BF535 PCI peripheral.
From: Analog Devices ADSP-BF535 Blackfin Processor PCI Interface Host Mode Application Note
What voltage and frequency ratings does the PCI bus interface on the ADSP-BF535 Processor support?
The interface is Revision 2.2, 3.3V-compliant, and operates at 33 MHz with a 32-bit width.
From: Analog Devices ADSP-BF535 Blackfin Processor PCI Interface Host Mode Application Note
What is the purpose of this document?
The purpose is to familiarize the user with the ADSP-BF535 Blackfin Processor's Peripheral Component Interconnect (PCI) interface in Device mode.
From: Analog Devices ADSP-BF535 Blackfin Processor PCI Interface Device Mode Application Note
