Analog Devices AD5280/AD5282 Digital Potentiometer Datasheet
The AD5280 (single‑channel) and AD5282 (dual‑channel) are 256‑position, I2C‑compatible digital potentiometers with selectable fixed terminal resistances of 20 kΩ, 50 kΩ or 200 kΩ and a temperature coefficient of 30 ppm/°C. They operate from a +10 V to +15 V single supply or ±5.5 V dual‑supply and include programmable logic outputs and a shutdown function.
The document details electrical characteristics, absolute maximum ratings, thermal resistance, pin configurations, typical performance curves, and an ordering guide. It also covers interface timing, test circuits, and application information such as using the devices for gain control, programmable voltage/current sources, and impedance matching.
Analog Devices AD5282 specifications
| Supply Voltage Range | +10 V to +15 V single supply; ±5.5 V dual‑supply |
|---|---|
| Fixed Terminal Resistance Options | 20 kΩ, 50 kΩ, 200 kΩ |
| Temperature Coefficient | 30 ppm/°C |
| Resolution | 8 bits |
| Number of Channels | 1 channel (AD5280) or 2 channels (AD5282) |
| Operating Temperature Range | -40 °C to +85 °C |
| Shutdown Current (ISHDN) | 5 µA |
Source: Analog Devices AD5280/AD5282 Digital Potentiometer Datasheet
All Analog Devices AD5282 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What supply voltage range does the AD5280/AD5282 support?
The devices operate from +10 V to +15 V with a single supply or ±5.5 V with a dual supply.
From: Analog Devices AD5280/AD5282 Digital Potentiometer Datasheet
How many bits of resolution do the AD5280/AD5282 provide?
Both parts have an 8‑bit resolution.
From: Analog Devices AD5280/AD5282 Digital Potentiometer Datasheet
What is the default wiper position at power‑on?
The wiper position defaults to midscale when power is applied.
From: Analog Devices AD5280/AD5282 Digital Potentiometer Datasheet
How many channels does the AD5282 have?
The AD5282 provides two independent channels.
From: Analog Devices AD5280/AD5282 Digital Potentiometer Datasheet
