TP-LINK TL-WR941N 11N Wireless broadband Router Detailed Reference Manual
This guide explains how to install, configure, and manage the TL‑WR941N wireless router. It covers hardware description, quick installation, and step‑by‑step configuration of network, wireless, and security settings.
The manual also details advanced functions such as parental controls, dynamic DNS, firmware upgrades, and system tools, plus a FAQ section for common troubleshooting questions. This manual is written in Chinese.
TP-Link TL-WR941N specifications
| Wireless Standard | IEEE 802.11b/g/n |
|---|---|
| Maximum Data Rate | 300 Mbps |
| LAN Ports | 4 × 10/100 M RJ45 |
| WAN Port | 1 × 10/100 M RJ45 |
| Frequency Range | 2.4 – 2.4835 GHz |
| Antenna Count | 3 |
| Transmit Power | 20 dBm (max) |
| Dimensions (L×W×H) | 200 mm × 140 mm × 28 mm |
| Operating Temperature | 0 °C to 40 °C |
Source: TP-LINK TL-WR941N 11N Wireless broadband Router Detailed Reference Manual
All TP-Link TL-WR941N documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I restore the router to factory defaults?
Select the 'Restore Factory Settings' option in the System Tools section or press the Reset button on the device.
From: TP-LINK TL-WR941N 11N Wireless broadband Router Detailed Reference Manual
How is the DHCP server configured?
Enable and set DHCP parameters in the LAN settings section of the Configuration Guide.
From: TP-LINK TL-WR941N 11N Wireless broadband Router Detailed Reference Manual
