TOSHIBA 1SV309 handbook
Datasheet 2 pages · 100 KB · EN
This document is a technical datasheet for the Toshiba SV309, a silicon epitaxial planar type diode designed for UHF and SHF tuning. Key features include a high capacitance ratio of approximately 5.7 (typical) and low series resistance of 1.2 ohms (typical). The device is suitable for small size tuners due to its excellent C-V characteristics.
Read onlineToshiba 1SV309 specifications
| Reverse Voltage (VR) | 30 V |
|---|---|
| Peak Reverse Voltage (VRM) | 1.20 Ohms (Typ.) |
| Junction Temperature (Tj) | 125 °C |
| Storage Temperature Range (Tstg) | -55~125 °C |
| Capacitance Ratio (Coy/Casy) | 5.7 (Typ.) |
Source: TOSHIBA 1SV309 handbook
All Toshiba 1SV309 documents by type
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum reverse voltage rating for this diode?
The device has a maximum reverse voltage rating of 30 V.
From: TOSHIBA 1SV309 handbook
What is the typical capacitance ratio (Coy/Co5yv) for this component?
The typical capacitance ratio is 5.7.
From: TOSHIBA 1SV309 handbook
