Key facts
- Brand
- Toshiba
- Model
- P300
- Category
- Other Computer Accessories
- Documents
- 3
- Languages
- EN
- Last added
- 2012-06-01
Start here
Toshiba P300/P300D Series Portable PC User Manual
This manual covers safety guidelines, power and battery handling, and environmental restrictions for the Toshiba P300/P300D Series portable computer. It explains how to avoid overheating, short‑circuit hazards, and proper use of the AC adapter and batteries.
The document also details network compatibility, ENERGY STAR compliance, and optical disc drive safety, along with an index of hardware components and troubleshooting procedures.
Toshiba P300 specifications
| Peak Off‑State Voltage | 250 V Min |
|---|---|
| On‑State Current | 100 mA Max |
| Isolation Voltage | 5000 V Min |
| Maximum Operating Insulation Voltage | 890 Vpk |
| Highest Permissible Over‑Voltage | 8000 Vpk |
| Creepage Distance (Min) | 7.0 mm / 8.0 mm |
| Clearance (Min) | 7.0 mm / 8.0 mm |
| Insulation Thickness (Min) | 0.5 mm |
| Weight | 0.39 g |
Source: TOSHIBA TLP3012(s) TLP3009(s) TLP3010(s) TLP3011(s) Manual
All Toshiba P300 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the peak off‑state voltage rating of the TLP3009 series?
The peak off‑state voltage is 250 V minimum.
From: TOSHIBA TLP3012(s) TLP3009(s) TLP3010(s) TLP3011(s) Manual
What is the maximum on‑state current for these phototriacs?
The maximum on‑state current is 100 mA.
From: TOSHIBA TLP3012(s) TLP3009(s) TLP3010(s) TLP3011(s) Manual
What safety standard does the TLP3009(D4) series comply with?
The series is tested under VDE0884 requirements and carries the VDE0884 option marking.
What is the maximum input current for the TLP3009(D4) series?
The maximum input current is 400 mA.
What safety precautions should be taken when using the Toshiba P300/P300D Series laptop?
Do not operate the portable computer with the base resting directly on your body, and avoid carrying the battery in a pocket with metal objects that could short‑circuit the terminals.
What voltage ranges are supported by the AC adapter?
The AC adapter supports 115V/60 Hz (North and South America), 100 V/50 Hz (eastern Japan), 100 V/60 Hz (western Japan), and 230 V/50 Hz (Europe, Middle East, Far East).
