Omron E3X-DA-S/MDA Series Digital Fiber Sensor Instruction Sheet
The Omron E3X-DA-S/MDA Series Digital Fiber Sensor Instruction Sheet describes precautions required for installing and operating the Amplifier Unit and Fiber Unit. It identifies the package contents, part names, display and key functions, and the SET/RUN operating modes.
The document explains basic settings such as light-ON/dark-ON selection, power adjustment, manual and automatic teaching, reflective-sensor teaching, and maximum-sensitivity threshold setting. It also lists ratings and specifications, display information, key operations, and precautions for correct and safe use.
Omron E3X-DA-S specifications
| Supply voltage | 12 to 24 VDC ±10% |
|---|---|
| Power consumption | 960 mW max (40 mA at 24 VDC) |
| Response time (turn‑on) | 50 µs |
| Resolution | 4000 digits |
| Weight (packed) | ≈ 100 g |
| Enclosure rating | IP50 |
| Light source (red LED) | 650 nm |
All Omron E3X-DA-S documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the turn‑on response time of the E3X‑DA‑S sensor?
The sensor turns on in 50 µs.
What voltage range does the E3X‑DA‑S operate on?
It operates from 12 VDC to 24 VDC with a ±10 % tolerance.
What supply voltage does the E3X-DA-S Series require?
It requires 12 to 24 VDC ±10% with ripple (p-p) 10% max.
From: Omron E3X-DA-S/MDA Series Digital Fiber Sensor Instruction Sheet
How long should a key be pressed when no specific time is given?
Press the key for approximately 1 second, then release it.
