Philips HF-P 1 22-42 PL-T/C/L/TL5C EII 220-240V User Manual
This manual describes the Philips HF‑P 1 22‑42 PL‑T/C/L/TL5C EII high‑frequency electronic ballast, designed for use with PL‑T, C, L and TL5C fluorescent lamps. It outlines overall parameters, operating features, and safety information.
Key sections include product data, wiring requirements, temperature limits, physical dimensions, and a list of applicable certifications such as EN 55015, IEC 61347‑2‑3 and ISO 9000. The document also provides ordering codes and packaging details. This manual is written in Chinese.
Philips TL5C specifications
| Rated lamp quantity | 1 piece |
|---|---|
| Lamp power | 22-42 W |
| Lamp type | PL‑T/C/L/TL5C |
| Input voltage | 220‑240 V |
| Operating frequency | 45 kHz |
| Power factor | 0.95 |
| Ballast lifetime | 50000 hr |
Source: Philips HF-P 1 22-42 PL-T/C/L/TL5C EII 220-240V User Manual
All Philips TL5C documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What lamp types are compatible with this ballast?
The ballast is compatible with PL‑T, C, L and TL5C fluorescent lamps.
From: Philips HF-P 1 22-42 PL-T/C/L/TL5C EII 220-240V User Manual
What is the input voltage range?
The ballast operates on an input voltage of 220‑240 V.
From: Philips HF-P 1 22-42 PL-T/C/L/TL5C EII 220-240V User Manual
