Linear Technology LTC2274 16-bit ADC Datasheet
The document introduces the LTC2274 as a 105Msps, 16-bit ADC that simplifies digital connections by replacing parallel interfaces with a novel high-speed serial interface. This design reduces data input/output lines from 16 CMOS or 32 LVDS to a single self-clocking differential pair communicating at 2.1Gbps.
Read onlineLinear Technology LTC2274 specifications
| Sample Rate | 105Msps |
|---|---|
| Resolution | 16-bit |
| Signal to Noise Ratio (SNR) | 77.6dBFS |
| Spurious Free Dynamic Range (SFDR) | 100dB |
| Serial Data Rate | 2.1Gbps |
All Linear Technology LTC2274 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the primary interface type of the LTC2274?
The device uses a novel high speed serial interface to replace traditional parallel devices.
How does the LTC2274 reduce I/O lines?
It reduces required data input/output lines from 16 CMOS or 32 LVDS parallel data lines to a single, self-clocking, differential pair.
What is the maximum sample rate of the LTC2274 ADC?
The LTC2274 has a sample rate of 105Msps.
From: linear DESIGN FEATURES LTMag-V19N4-14-LTC2274-ClarenceMayott service manual
What bandwidth does the signal chain in Figure 1 support?
The signal chain supports a bandwidth of 20MHz.
From: linear DESIGN FEATURES LTMag-V19N4-14-LTC2274-ClarenceMayott service manual
What are the stated resolution and sample rate of the LTC2274?
The device is a 16-bit, 105Msps ADC.
What are the stated SNR and spurious free dynamic range ratings?
It has 77dB of SNR and 100dB of spurious free dynamic range.
