Analog Devices LTM4616 Dual 8A DC/DC Module Regulator Design Ideas
This document presents design applications for the LTM4616, a dual input and dual output DC/DC module regulator housed in a 15mm x 15mm x 2.8mm LGA surface mount package. The device integrates switching controllers, MOSFETs, an inductor, and support components to require only a few external parts.
Read onlineAll Linear Technology LTM4616 documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the maximum continuous output current for each regulator in the LTM4616?
Each regulator provides up to 8A of continuous output current.
From: Analog Devices LTM4616 Dual 8A DC/DC Module Regulator Design Ideas
What is the maximum total output current when two LTM4616 regulators are operated in parallel?
The part can deliver a total output current of 16A when operating in a 2-phase parallel mode.
From: Analog Devices LTM4616 Dual 8A DC/DC Module Regulator Design Ideas
What is the maximum programmable average charge current for the LTC3625?
The device features a programmable average charge current up to 1A.
From: Linear Technology Supercapacitor-Based Power Backup Design Note 487
How long does it take to recharge the supercapacitor stack in the design example?
The desired recharge time for the system is ten minutes.
From: Linear Technology Supercapacitor-Based Power Backup Design Note 487
