Key facts
- Brand
- Linear Technology
- Model
- LTC1628
- Category
- Power Management
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-05
Start here
Linear Technology AN77 PolyPhase Converters for High Current Applications
As logic systems require higher currents, paralleling several power regulators is often necessary. This document introduces smart PolyPhase techniques that interleave clock signals to reduce input and output ripple current without increasing switching frequency. By using the LTC1629 or LTC1628 controllers, designers can achieve high efficiency and use smaller components like inductors and capacitors.
Read onlineLinear Technology LTC1628 specifications
| Input Voltage Range | 3.5 V to 36 V |
|---|---|
| Output Voltage Accuracy | ±1 % |
| Switching Frequency | 150 kHz to 300 kHz |
| Shutdown Current (RUN/SS pin) | 20 µA |
All Linear Technology LTC1628 documents by type
How to use the product for one specific task, with worked examples.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
How do PolyPhase converters reduce ripple current?
They interleave the clock signals of paralleled power stages, which reduces input and output ripple current without increasing the switching frequency.
From: Linear Technology AN77 PolyPhase Converters for High Current Applications
What is the benefit of using LTC1629 for high current designs?
The LTC1629 solves problems related to complex timing and current-sharing requirements for high current, single output designs.
From: Linear Technology AN77 PolyPhase Converters for High Current Applications
What is the recommended input voltage range for the LTC1628?
The controller operates with an input voltage from 3.5 V up to 36 V.
How accurate is the output voltage regulation?
The output voltage is regulated to within ±1 % of the nominal value.
