LINEAR dn351f handbook
Application Note 2 pages · 69 KB · EN
This document is a design note (DN-351) for the Linear Technology Corporation LT6650 voltage reference IC. It details how to use the device as a series or shunt regulator with programmable output voltages ranging from 0.4V to 18V.
Read onlineLinear Technology LT6650 specifications
| Supply Voltage Range | 1.4 V to 18 V |
|---|---|
| Operating Temperature Range | -40 °C to 125 °C |
| Package Type | 5‑lead plastic TSOT‑23 |
| Output Short‑Circuit Duration | Indefinite |
| Short‑Circuit Output Current | 5 mA |
All Linear Technology LT6650 documents by type
Application Note 1
How to use the product for one specific task, with worked examples.
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the minimum supply voltage required to operate the LT6650?
The device can operate on a single supply down to 1.4V.
From: LINEAR dn351f handbook
What is the maximum output voltage the LT6650 can produce?
The unit may be powered by or produce reference voltages up to 18V.
From: LINEAR dn351f handbook
What is the supply voltage range of the LT6650?
The LT6650 operates from 1.4 V up to 18 V.
What temperature range can the LT6650 operate in?
It can operate from –40 °C to 125 °C.
