Start here
LINEAR 2PB_6409 Differential Amplifiers High Speed ADC Drivers
This document provides technical specifications for a range of Fixed Gain IF Differential Amplifiers/ADC Drivers from Linear Technology. Key models include the LTC6409 series, which offers up to 110 MHz bandwidth with high dynamic range (80dBc), and the LTC6412 Variable Gain Amplifier featuring continuous gain control from -14 dB to +17 dB.
Read onlineLinear Technology LTC6601 specifications
| Bandwidth (LTC6409) | 110 MHz |
|---|---|
| Input Noise Density (LTC6409) | 27 nV/VHz |
| Gain Range (LTC6412) | -14 dB to +17 dB |
| OIP3 at 240MHz (LTC6412) | 35 dBm |
| Noise Figure (LTC6412) | 10 dB |
Source: LINEAR 2PB_6409 Differential Amplifiers High Speed ADC Drivers
All Linear Technology LTC6601 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the input noise density of the LTC6409?
The LTC6409 has an input noise density of 27 nV/VHz.
From: LINEAR 2PB_6409 Differential Amplifiers High Speed ADC Drivers
What is the gain range for the LTC6412?
The LTC6412 offers a linear-in-dB gain range from -14 dB to +17 dB.
From: LINEAR 2PB_6409 Differential Amplifiers High Speed ADC Drivers
What is the typical oscillator frequency when the BOOST pin is left open?
With the BOOST pin open, the internal oscillator runs at about 10 kHz.
From: Linear Technology LTC660 100mA CMOS Voltage Converter Datasheet
What is the efficiency of the LTC660 at no load?
At no load the converter achieves roughly 99 % efficiency, up to 99.96 % in the best case.
From: Linear Technology LTC660 100mA CMOS Voltage Converter Datasheet
