Linear Technology LT3083/LT3080 Linear Regulator Application Note
The document introduces a new architecture for 3-terminal linear regulators that replaces the traditional voltage reference with a precision current source. This design allows for fixed frequency response and load regulation, eliminating issues associated with resistor dividers in traditional designs.
A key benefit of this architecture is the ability to easily parallel multiple LT3083 or LT3080 devices to spread power dissipation and increase output current. By connecting the SET pins together, a common reference point is established, allowing for simple load balancing with minimal ballast resistors.
All Linear Technology LT3080 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum output current capability of the LT3083?
The LT3083 has an increased 3A output current capability.
From: Linear Technology LT3083/LT3080 Linear Regulator Application Note
What is the minimum load current requirement for the LT3083?
The device requires a minimum of 0.5mA load current.
From: Linear Technology LT3083/LT3080 Linear Regulator Application Note
