Start here
Linear Technology LTC1592 16-Bit Softspan DAC Quick Start Guide
This guide provides instructions for setting up and testing the LTC1592, a 16-bit current output DAC with five software-selectable output ranges. It includes hardware setup, connection to a DC590 USB Serial Controller, and procedures for measuring offset error, gain error, settling time, and glitch impulse. The board is designed for easy evaluation and direct integration into applications using the provided software and tools.
The guide details power connections, jumper settings, output and reference connections, and step-by-step procedures for measuring performance metrics. It also includes figures illustrating step response and glitch impulse characteristics, with recommendations for oscilloscope use and measurement accuracy.
Linear Technology LTC1592 specifications
| DAC Resolution | 16-bit |
|---|---|
| Output Type | Current Output |
| Output Ranges | Five software-selectable output ranges |
Source: Linear Technology LTC1592 16-Bit Softspan DAC Quick Start Guide
All Linear Technology LTC1592 documents by type
The shortest path to a working setup, usually only a few pages.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the default power supply requirement for the DC572 board?
A regulated, +/-15VDC power supply must be connected to the power connections on DC572.
From: Linear Technology LTC1592 16-Bit Softspan DAC Quick Start Guide
How do I connect the DC572 to the DC590 USB Serial Controller?
Connect DC572 to DC590 using the supplied 14 conductor ribbon cable, and connect DC590 to the host PC with a standard USB A/B cable.
From: Linear Technology LTC1592 16-Bit Softspan DAC Quick Start Guide
What industrial voltage ranges does the LTC1592 provide?
The device provides accurate outputs for all standard industrial ranges including 0V to 5V, 0V to 10V, –5V, –10V, –2.5V and –2.5V to 7.5V.
From: LINEAR Multiple Output Range 16-Bit DAC Design Made Simple Design Note 337 handbook
How much PCB space does a full implementation of the LTC1592 require?
A complete implementation takes less than 0.5in · 0.5in when including the dual operational amplifier, bypass and compensation.
From: LINEAR Multiple Output Range 16-Bit DAC Design Made Simple Design Note 337 handbook
How many programmable output ranges does the device support?
The device supports six programmable output ranges: two unipolar and four bipolar.
From: Linear Technology LTC1588/LTC1589/LTC1592 12-/14-/16-Bit SoftSpan DACs Datasheet
What is the typical glitch impulse of the DAC?
The typical glitch impulse is less than 2 nV‑s.
From: Linear Technology LTC1588/LTC1589/LTC1592 12-/14-/16-Bit SoftSpan DACs Datasheet
