Linear Technology AN11 Designing Linear Circuits for 5V Single Supply Operation Application Note
The document addresses the challenges of powering analog components directly from a 5V digital rail, which is often noisy due to logic clocking. It explains that while high-performance applications usually require dedicated supplies, many standard analog functions can be successfully implemented with good design practices using the logic supply.
The note presents several specific circuit examples designed for 5V single-supply operation. These include a linearized signal conditioner for platinum RTDs, a methane detector transducer circuit, a cold junction compensated thermocouple conditioner, and two types of precision instrumentation amplifiers (one standard and one ultra-precision chopper-stabilized).
Linear Technology AN11 specifications
| Minimum Input Voltage (JFET) | 300mV to 1.6V |
|---|---|
| Maximum Output Current (JFET) | 2mA |
| Minimum Input Voltage (Bipolar) | 300mV (running) / 550mV (start) |
| Maximum Output Current (Bipolar) | 6mA |
| Output Voltage Range (APD Bias) | 200V from 5V |
