Start here
linear DESIGN FEATURES LTJournal-V21N2-03-df-LTC2870_71-Steven_Tanghe service manual
The LTC2870 and LTC2871 are multiprotocol transceivers designed to simplify applications using both RS485 and RS232 standards. The LTC2870 combines two RS232 transceivers with one RS485 transceiver on shared I/O pins, while the LTC2871 offers separate pinouts for all three transceivers allowing simultaneous operation.
Read onlineLinear Technology LTC2870 specifications
| Supply Voltage Range | 1.8V to 5.5V |
|---|---|
| RS485 Data Rate | 20Mbps |
| RS232 Data Rate | 500kbps |
| ESD Rating (LTC2870) | +26kV |
| ESD Rating (LTC2871/72) | +16kV |
| RS485 Termination Resistance | 120 Ohm |
Source: LINEAR 2PB_multiprotocolf LTC2870/LTC2871/LTC2872 Multiprotocol Transceivers
All Linear Technology LTC2870 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum data rate for the RS485 transceiver?
The device supports data rates as high as 20Mbps for the single RS485 transceiver.
From: linear DESIGN FEATURES LTJournal-V21N2-03-df-LTC2870_71-Steven_Tanghe service manual
What is the maximum data rate for the RS232 transceivers?
The device supports data rates up to 50kbps for two RS232 transceivers.
From: linear DESIGN FEATURES LTJournal-V21N2-03-df-LTC2870_71-Steven_Tanghe service manual
What protocols do the LTC2870/71/72 support?
These devices support RS232, RS485, and RS422 protocols.
From: LINEAR 2PB_multiprotocolf LTC2870/LTC2871/LTC2872 Multiprotocol Transceivers
Can the termination resistors be switched automatically?
Yes, they integrate pin-controlled termination resistors that automatically switch in or out to match the protocol selection.
From: LINEAR 2PB_multiprotocolf LTC2870/LTC2871/LTC2872 Multiprotocol Transceivers
