Linear Technology LTC3736 Manuals

ManualLib has 2 documents for the Linear Technology LTC3736 (Power System Manager): 1 product leaflet, 1 datasheet. Every file can be read online or downloaded as a PDF for free.

Product Leaflet 1Datasheet 1

Key facts

Model
LTC3736
Documents
2
Languages
EN
Last added
2012-06-05

Start here

Linear Technology Dual Output DC/DC Converter Solutions for Xilinx FPGA Based Systems Handbook

Linear Technology Dual Output DC/DC Converter Solutions for Xilinx FPGA Based Systems Handbook

Product Leaflet 4 pages · 178 KB · EN

The document addresses the power requirements of Xilinx FPGAs, which need multiple voltage rails including Vecint, Veco, and sometimes Vecaux. It highlights the importance of supply sequencing, tracking, and ramp time in these applications.

Three specific dual output DC/DC regulators are detailed: the LTC3407 for currents up to 600mA, the LTC3736 for 5A loads using 2-phase operation, and the LTC3708 for high-current applications exceeding 10A. The text provides application schematics, efficiency curves, and feature descriptions such as output tracking and programmable current limits.

Read online

Linear Technology LTC3736 specifications

Max Supply Current (LTC3407)600mA
Input Voltage Range (LTC3407)2.5V to 5.5V
Output Voltage Range (LTC3407)0.6V to 5V
Max Supply Current (LTC3736)5A
Input Voltage Range (LTC3736)2.7V to 9.8V
Max Supply Current (LTC3708)15A
Input Voltage Range (LTC3708)3.3V up to 36V
Output Voltage Range (LTC3708)down to 0.6V

Source: Linear Technology Dual Output DC/DC Converter Solutions for Xilinx FPGA Based Systems Handbook

All Linear Technology LTC3736 documents by type

Datasheet 1

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in these manuals

What are the core voltage requirements for Xilinx FPGAs?

Core voltages range from 1.2V to 2.5V, with some mature products having 3V, 3.3V, or 5V.

From: Linear Technology Dual Output DC/DC Converter Solutions for Xilinx FPGA Based Systems Handbook

What is the recommended ramp time for FPGA core voltage?

The recommended ramp time (teepo) for the core voltage Vecint is less than 50ms during power-on.

From: Linear Technology Dual Output DC/DC Converter Solutions for Xilinx FPGA Based Systems Handbook

What is the input voltage range for the LTC3736?

The device operates from –0.3 V up to 10 V on the Vin pin.

From: Linear Technology LTC3736 Datasheet

What is the maximum switching frequency the LTC3736 can achieve?

When synchronized to an external clock, the LTC3736 can run up to 850 kHz.

From: Linear Technology LTC3736 Datasheet
