Key facts
- Brand
- Linear Technology
- Model
- LTM9004
- Category
- Other Electronics
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-05
Start here
Linear Technology LTM9004 UMTS Receiver Application Note
The document presents a design analysis for the LTM9004 pModule receiver, which implements a direct conversion architecture using SiGe high-frequency components and fine-line CMOS ADCs. It details how this receiver fits within a half-inch square package to meet macrocell base station performance requirements while maintaining high integration.
Read onlineLinear Technology LTM9004 specifications
| ADC Resolution | 14-Bit |
|---|---|
| ADC Sampling Rate | 125Msps |
| LTM9004 RF Input Range | 700MHz to 2.7GHz |
| LTM9005 RF Input Range | 400MHz to 3.8GHz |
| Package Size | 22mm x 15mm LGA Package |
Source: LINEAR 2PB_9004_signalchain RF-to-Digital Module Receivers
All Linear Technology LTM9004 documents by type
How to use the product for one specific task, with worked examples.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the physical size of the LTM9004 package?
The receiver occupies a package measuring 15mm x 22mm.
From: Linear Technology LTM9004 UMTS Receiver Application Note
What is the total power consumption of the LTM9004-AC?
The device consumes a total of 1.83 W from 5 V and 3 V supplies.
From: Linear Technology LTM9004 UMTS Receiver Application Note
What is the RF input range for the LTM9004 receiver?
The LTM9004 supports an RF input range from 700MHz to 2.7GHz.
From: LINEAR 2PB_9004_signalchain RF-to-Digital Module Receivers
What is the total power consumption of the LTM9005 receiver?
The LTM9005 operates with a 3.3V supply and consumes 1.3W total.
From: LINEAR 2PB_9004_signalchain RF-to-Digital Module Receivers
