Start here
Analog Devices AD204 Isolation Amplifier Handbook
The AD204 isolation amplifier is a low‑power, miniature isolation device offering up to +2000 V peak continuous common‑mode isolation, 130 dB CMR at a gain of 100 V/V, and a 5 kHz full‑power bandwidth. It includes an uncommitted input op‑amp and can supply isolated +7.5 V power at 2 mA for auxiliary circuits.
The handbook covers functional block diagrams, power options (the AD204 is powered by an external clock driver such as the AD246), detailed specifications, wiring examples, adjustment procedures, and performance notes on common‑mode rejection, noise, and output filtering.
Analog Devices AD204 specifications
| Gain range | 1 V/V – 100 V/V |
|---|---|
| Power consumption (AD204) | 35 mW |
| Bandwidth (full‑power) | 5 kHz |
| CMRR (gain = 100 V/V) | 130 dB |
| Output resistance (AD204) | 3 kΩ |
| Leakage current (input to output @ 240 V rms) | 2 mA rms max |
Source: Analog Devices AD202/AD204 Isolation Amplifiers Datasheet
All Analog Devices AD204 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the power consumption of the AD204 isolation amplifier?
The AD204 consumes 35 mW of power over the full signal range.
From: Analog Devices AD202/AD204 Isolation Amplifiers Datasheet
What is the power consumption of the AD204?
The AD204 consumes 35 mW of power over the full signal range.
What is the maximum isolation voltage of the AD204?
The device provides up to +2000 V peak continuous isolation between input and output.
