Linear Technology LTC3713 Synchronous Buck DC/DC Controller Manual
This manual describes the LTC3713 low‑input voltage, high‑power synchronous buck DC/DC controller. It highlights features such as no‑sense‑resistor operation, adjustable current limit, and support for input voltages as low as 0.8 V.
The document includes absolute maximum ratings, electrical characteristics, typical performance graphs, pin function descriptions, functional diagrams, package details, and a typical application circuit. Engineers can use it to design power supplies and understand the device’s operation and limits.
Linear Technology LTC3713 specifications
| Input Supply Voltage (VINA) range | 10 V to -0.3 V |
|---|---|
| Boosted Topside Driver Supply Voltage (BOOST) range | 42 V to -0.3 V |
| Junction Temperature (max) | 125 °C |
| Package type | 24‑Lead Plastic SSOP |
Source: Linear Technology LTC3713 Synchronous Buck DC/DC Controller Manual
All Linear Technology LTC3713 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the input voltage range for the LTC3713?
The device can tolerate an input supply voltage from 10 V down to –0.3 V.
From: Linear Technology LTC3713 Synchronous Buck DC/DC Controller Manual
What package does the LTC3713 use?
It is supplied in a 24‑lead plastic SSOP package.
From: Linear Technology LTC3713 Synchronous Buck DC/DC Controller Manual
What is the shutdown supply current of the LTC3713?
The shutdown supply current is specified as 15 pA to 30 pA.
Which pin provides the Run control and soft‑start input?
Pin 1 (RUN/SS) is the Run Control and Soft‑Start Input.
