Analog Devices UG-326 Manuals

ManualLib has 2 documents for the Analog Devices UG-326: 2 datasheets. Every file can be read online or downloaded as a PDF for free.

Datasheet 2

Key facts

Model
UG-326
Industry
Industrial
Documents
2
Languages
EN
Last added
2012-08-02

Start here

ANALOG DEVICES UG-326 handbook (1)

ANALOG DEVICES UG-326 handbook (1)

User Manual 8 pages · 94 KB · EN

This document is the user guide for the EVAL-ADMP441Z daughter board, which works with the EVAL-ADMP441Z-FLEX board and the System Demonstration Platform (SDP) to evaluate the ADMP441 I2S MEMS microphone. The evaluation kit allows users to stream two channels of audio from two microphones to a PC over a USB connection without requiring additional drivers or software.

Read online

Analog Devices UG-326 specifications

Supply Voltage1.8 V to 3.3 V dc
Clock Input Frequency1.0 MHz to 3.3 MHz
Output Signal TypePDM digital output
Bypass Capacitor0.1 μF

Source: ANALOG DEVICES UG-326 handbook

All Analog Devices UG-326 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the EVAL-ADMP521Z-FLEX used for?

It allows quick evaluation of the performance of the ADMP521 MEMS microphone.

From: ANALOG DEVICES UG-326 handbook

What is the supply voltage range?

The power supply range is 1.8 V to 3.3 V dc.

From: ANALOG DEVICES UG-326 handbook

Do I need to install drivers for the EVAL-ADMP441Z system?

No, the system identifies itself as a standard USB audio interface, so no additional drivers or software are required.

From: ANALOG DEVICES UG-326 handbook (1)

How do I enable the microphones on the board?

Push both switches of S1 to the right (enable) position to enable the microphones.

From: ANALOG DEVICES UG-326 handbook (1)
