Start here
Analog Devices AD9238 12‑Bit Dual ADC Datasheet
The AD9238 is a dual‑channel, 12‑bit analog‑to‑digital converter that operates from a single 3 V supply (2.7 V‑3.6 V). It offers selectable sampling rates of 20 MSPS, 40 MSPS, or 65 MSPS, low power consumption, and a clock‑duty‑cycle stabilizer for robust performance across a wide range of clock conditions.
The document provides full DC, AC, digital, and switching specifications, absolute maximum ratings, pin descriptions, typical performance characteristics, and mechanical details such as package dimensions and ordering options. Evaluation board schematics and bill‑of‑materials are also included for design reference.
Analog Devices AD9238 specifications
| Resolution | 12 bits |
|---|---|
| Accuracy (Missing Codes) | No missing codes guaranteed |
| Power Consumption (65 MSPS) | 300 mW per channel |
| Operating Temperature Range | −40 °C to +85 °C |
All Analog Devices AD9238 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum sampling rate of the AD9238?
The AD9238 supports up to 65 MSPS sampling rate.
What supply voltage does the AD9238 require?
It operates from a single 3 V supply, ranging from 2.7 V to 3.6 V.
What is the maximum conversion rate of the AD9238?
The device can operate at up to 65 MSPS, with lower options of 40 MSPS and 20 MSPS.
What are the power consumption levels for the different speed grades?
At 20 MSPS the AD9238 consumes about 180 mW, at 40 MSPS about 330 mW, and at 65 MSPS about 600 mW.
