Analog Devices AD537 Datasheet
The AD537 is a precision current‑to‑frequency converter that operates from a single supply of 4.5 V to 36 V (or dual supply ±5 V to ±18 V). It provides a frequency output from 0 kHz up to 150 kHz with low non‑linearity and a high‑impedance input stage for voltage‑to‑current conversion. The document includes full specifications, typical application circuits, calibration procedures, and protection guidelines.
Additional sections cover output interfacing to digital logic families, synchronous operation via the SYNC pin, temperature‑to‑frequency conversion, and two‑wire data transmission. Application examples illustrate how the AD537 can be used for voltage‑to‑frequency, temperature‑to‑frequency, and PLL‑based V‑to‑F conversions.
Analog Devices AD537 specifications
| Frequency Range | 0 kHz to 150 kHz |
|---|---|
| Supply Voltage (Single Supply) | 4.5 V to 36 V |
| Supply Voltage (Dual Supply) | ±5 V to ±18 V |
| Quiescent Current | 1.2 mA (2.5 mA max) |
| Input Bias Current | 100 nA |
| Output Sink Current (Logic 0) | 20 mA min |
| Temperature Range (Rated Performance) | 0°C to +70°C |
Source: Analog Devices AD537 Datasheet
All Analog Devices AD537 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the frequency range of the AD537?
The AD537 can generate frequencies from 0 kHz up to 150 kHz.
What supply voltages does the AD537 support?
It operates from a single supply of 4.5 V to 36 V or a dual supply of ±5 V to ±18 V.
What supply voltage range does the AD537 support?
The AD537 operates from a single supply of 4.5 V to 36 V.
How much quiescent current does the AD537 draw?
It consumes 1.2 mA quiescent current (up to 2.5 mA max).
