Key facts
- Brand
- Texas Instruments
- Model
- CY54
- Industry
- Industrial
- Documents
- 3
- Languages
- EN
- Last added
- 2012-06-08
Start here
Texas Instruments CY54/74FCT240T/CY54/74FCT244T Datasheet
Datasheet 8 pages · 95 KB · EN
This document is a technical datasheet for the CY54/74FCT240T and CY54/74FCT244T, which are octal buffers and line drivers designed to be employed as memory address drivers, clock drivers, and bus-oriented transmitters/receivers. The devices provide speed and drive capabilities equivalent to their fastest bipolar logic counterparts while reducing power consumption.
Read onlineTexas Instruments CY54 specifications
| Max Propagation Delay (FCT240T) | 9.0 ns |
|---|---|
| Max Propagation Delay (FCT244T) | 7.0 ns |
| Operating Temperature Range (Commercial) | -40°C to +85°C |
| ESD Protection Rating | > 2000V |
Source: Texas Instruments CY54/74FCT240T/CY54/74FCT244T Datasheet
All Texas Instruments CY54 documents by type
Datasheet 3
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
Are these devices compatible with TTL logic levels?
Yes, they are fully compatible with TTL input and output logic levels.
From: Texas Instruments CY54/74FCT240T/CY54/74FCT244T Datasheet
What are the operating ambient temperature limits for commercial grade parts?
The operating range is from -40°C to +85°C.
From: Texas Instruments CY54/74FCT240T/CY54/74FCT244T Datasheet
