STMicroelectronics STM32F2xx Manuals

ManualLib has 4 documents for the STMicroelectronics STM32F2xx (microcontrollers): 1 user manual, 3 application notes. Every file can be read online or downloaded as a PDF for free.

User Manual 1Application Note 3

Key facts

Model
STM32F2xx
Documents
4
Languages
EN
Last added
2022-12-29

Start here

User manual for STM32F series 32-bit Flash microcontrollers Motor Control Software Development Kit

User manual for STM32F series 32-bit Flash microcontrollers Motor Control Software Development Kit

User Manual 42 pages · 795 KB · EN

This document provides an advanced developer's guide for the STM32 PMSM FOC (Field Oriented Control) software library version 3.3. It focuses on the library's implementation using object-oriented programming (OOP) in C, detailing the architecture, classes, and their relationships. The library is designed for use with STM32F05xx, STM32F100xx, STM32F103xx, STM32F2xx, and STM32F4xx microcontrollers to control 3-phase Permanent Magnet Synchronous Motors (PMSM).

Read online

STMicroelectronics STM32F2xx specifications

Operating voltage supply (VDD)1.8 V to 3.6 V
WLCSP package operating voltage1.65 V to 3.6 V
Internal digital power1.2 V
Low-speed internal RC frequency32 kHz
Low-speed external crystal frequency32.768 kHz

Source: ST AN3430 handbook

All STMicroelectronics STM32F2xx documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What motors does this library control?

The library implements Field Oriented Control for 3-phase Permanent Magnet Synchronous Motors, covering both Surface Mounted and Internal types.

From: User manual for STM32F series 32-bit Flash microcontrollers Motor Control Software Development Kit

Which microcontrollers are supported?

This manual covers the STM32F05xx, STM32F100xx, STM32F103xx, STM32F2xx, and STM32F4xx microcontrollers.

From: User manual for STM32F series 32-bit Flash microcontrollers Motor Control Software Development Kit

What is the maximum EEPROM size supported by this emulation?

The emulated EEPROM size is flexible and depends on the limits and constraints of the sector size used.

From: AN3390 EEPROM Emulation in STM32F2xx Microcontrollers Application Note

Is the write operation interrupted by a software reset?

No, ongoing word write operations on STM32F2xx embedded Flash are not interrupted by a CPU reset.

From: AN3390 EEPROM Emulation in STM32F2xx Microcontrollers Application Note

What is the operating voltage range for the STM32F2xx microcontroller?

The device requires a 1.8 V to 3.6 V operating voltage supply (VDD), except for the WLCSP package which requires 1.65 V to 3.6 V.

From: ST AN3430 handbook

How should unused pins be connected to avoid external disturbance?

All unused pins must be connected to ground through a 10K pull-down resistor to avoid external disturbance on the I/Os and increase the EMC performance.

From: ST AN3430 handbook
