Key facts
- Brand
- Panasonic
- Model
- 12A
- Category
- video output amplifier
- Documents
- 5
- Languages
- EN
- Last added
- 2012-08-09
Start here
Panasonic KX-TG2511AL / KX-TG2512AL / KX-TG2513AL Digital Cordless Phone Operating Instructions
These operating instructions guide users of the Panasonic KX‑TG2511AL, KX‑TG2512AL and KX‑TG2513AL digital cordless phones. The manual includes safety warnings, product specifications, and detailed steps for installing the base unit, charging batteries, and configuring basic settings.
Key sections cover safety precautions, battery handling, base‑unit placement for optimal reception, making and answering calls, programming features such as Caller ID and intercom, and troubleshooting common issues. The document also provides accessory information, environmental guidelines, and warranty record‑keeping advice.
Panasonic 12A specifications
| Input Voltage | 15.1 V - 16 V |
|---|---|
| Current Capacity | 2.5 A |
| Operating Temperature | -5 C to 35 C |
| Dimensions (WxDxH) | Approx. 123 mm x 124mm x 97 mm |
| Weight | Approx. 650g |
Source: Panasonic CF-VCBP12AU Battery Charger Operating Instructions
All Panasonic 12A documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How long does it take to charge the battery pack?
The charging time is approximately 2 hours.
From: Panasonic CF-VCBP12AU Battery Charger Operating Instructions
What do the indicator lights mean?
Green indicates fully-charged, orange means charging, blinking red suggests a malfunction, and blinking orange indicates a temperature violation.
From: Panasonic CF-VCBP12AU Battery Charger Operating Instructions
Which camera is this lens designed for?
This 12X power servo control zoom lens is intended for use with the WV-D5000 system camera.
From: Panasonic WV-LZ14/12A 12X Power Servo Control Zoom Lens Installation Instructions
What type of batteries should be used with the phone?
Only rechargeable Ni‑MH AAA (R03) batteries should be used; alkaline, manganese or Ni‑Cd batteries are not allowed.
From: Panasonic KX-TG2511AL / KX-TG2512AL / KX-TG2513AL Digital Cordless Phone Operating Instructions
Can the phone make calls during a mains power failure?
No. The device cannot make calls when the mains power fails; a separate, non‑powered telephone should be used for emergencies.
From: Panasonic KX-TG2511AL / KX-TG2512AL / KX-TG2513AL Digital Cordless Phone Operating Instructions
