Key facts
- Brand
- Panasonic
- Model
- WV-CP240
- Category
- video output amplifier
- Documents
- 3
- Languages
- EN
- Last added
- 2012-08-08
Start here
Panasonic WV-CP240/WV-CP242/WV-CP244 CCTV Cameras Manual
This manual provides operating instructions for the Panasonic WV-CP240/CP242/CP244 series digital signal processing color CCD cameras. These models feature a 1/3-inch interline transfer CCD image sensor with 768 horizontal pixels and offer functions such as Auto Light Control, Automatic Gain Control, and Automatic Tracing White Balance.
Read onlinePanasonic WV-CP240 specifications
| Horizontal Resolution | 480 lines |
|---|---|
| Signal-to-Noise Ratio | 50 dB (AGC Off) |
| Power Supply (WV-CP242) | 12 V DC |
| Power Supply (WV-CP244) | 24 V AC 60 Hz |
Source: Panasonic WV-CP240/WV-CP242/WV-CP244 CCTV Cameras Manual
All Panasonic WV-CP240 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What lens mount types are supported?
The camera supports C-mount or CS-mount lenses.
From: Panasonic WV-CP240/WV-CP242/WV-CP244 CCTV Cameras Manual
What is the minimum illumination required for the WV-CP240/242/244 cameras?
The cameras require a minimum illumination of 0.6 lx (0.06 foot-candle) at F0.75.
From: Panasonic WV-CP240/WV-CP242/WV-CP244 CCTV Cameras Manual
What is the input power source for the WV-CP240EX?
The input power source is 120 V AC 60 Hz.
From: Panasonic WV-CP240EX/WV-CP242EX/WV-CP244EX CCTV Camera Manual
What are the operating temperature and humidity limits?
The camera should be used between -10 °C to +50 °C with humidity below 90 %.
From: Panasonic WV-CP240EX/WV-CP242EX/WV-CP244EX CCTV Camera Manual
