STMicroelectronics STM690A/STM692A/STM703/STM704/STM802/STM805/STM817/STM818/STM819 Supervisor Manual
The STM690A, STM692A, STM703, STM704, STM802, STM805, STM817, STM818 and STM819 supervisors are 5 V supervisory devices that provide reset, watchdog, battery‑switchover and power‑fail monitoring for microprocessor systems. They are offered in 8‑pin SOIC and TSSOP packages and support external LPSRAM non‑volatile storage.
The manual includes functional block diagrams, pin descriptions, timing waveforms, electrical characteristics, package mechanical data, ordering information and a revision history. It serves designers and system integrators who need to implement reliable power‑management and reset control in their designs.
STMicroelectronics STM8 specifications
| Internal registers | 6 internal registers |
|---|---|
| Addressing modes | 20 addressing modes |
| Instructions | 80 instructions |
| Program Counter size | 24-bit |
| Stack Pointer size | 16-bit |
| Condition flags | 7 Condition flags |
| Maximum memory addressable | 16-Mbyte |
| Interrupt vectors | up to 32 |
| Average instruction size | 2 bytes |
Source: STM8 CPU Programming Manual
All STMicroelectronics STM8 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- ST STM690A STM692A STM703 STM704 STM802 STM805 STM817/8/9 handbook 43 p
- ST STEVAL-IHM041V1 Universal motor driver with speed control based on the STM8 Triac (US version) handbook 4 p
- ST STM8/128-EV/TS STM8S touch sensing evaluation kit handbook
- STMicroelectronics STM8-TOUCH-LIB Touch Sensing Library Data Brief 9 p
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Instruction set, parameters and examples for configuring or programming the device.
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What is the average instruction size of the STM8 instruction set?
The instruction set is 8-bit oriented with a 2-byte average instruction size.
How many internal registers does the STM8 core contain?
The STM8 core contains 6 internal registers.
What is the watchdog timer time?
The internal watchdog timer runs out and triggers a reset if the input remains high or low for 1.6 seconds.
From: ST STM690A STM692A STM703 STM704 STM802 STM805 STM817/8/9 handbook
Which models have a power-fail comparator?
The power-fail comparator is available on most models except the STM818.
From: ST STM690A STM692A STM703 STM704 STM802 STM805 STM817/8/9 handbook
What modes of operation does the board support?
The board may be operated in either open loop mode or in closed loop speed control mode.
Can the board be used as a lamp dimmer?
Yes, the open loop mode may also be used as a lamp dimmer.
