Key facts
- Brand
- Siemens
- Model
- ET 200S FC
- Category
- Other device
- Industry
- Industrial
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2012-03-31
Start here
Siemens ET200S FC Quick Start Guide
This guide introduces the Siemens ET200S FC and provides step‑by‑step instructions for qualified personnel to install, configure and operate the device. It includes safety notes and specifies that only trained and authorized staff should use the software and hardware.
The document is organized into sections on function scope, hardware and software requirements, example installation programs, and detailed instructions for controlling the ET200S FC via the variable table, including parameter write procedures and fault handling.
Siemens ET 200S FC specifications
| Alternative CPU | ET200S IM 151‑7 CPU |
|---|---|
| Control Unit | ICU24 or ICU24 F control unit |
| Power Module | IPM25 power module |
| Software Version | STEP 7 V5.2 or higher, SP1 or higher |
| Hardware Support Package | HSP (Hardware Support Package) |
All Siemens ET 200S FC documents by type
The shortest path to a working setup, usually only a few pages.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Who is allowed to use the ET200S FC quick start guide?
Only qualified personnel who have the necessary knowledge and authorization may install, configure, debug, operate, and maintain the product.
What software version is required to program the ET200S FC?
STEP 7 V5.2 or later, with SP1 or higher and the hardware support package (HSP) installed.
Which communication protocols are supported?
The transformer supports PROFIBUS and PROFINET interfaces.
What are the operating temperature limits?
The operating temperature range is 0 °C to +40 °C (0 °F to +104 °F).
