Key facts
- Brand
- Siemens
- Model
- 3VU16
- Category
- Industrial Supply
- Industry
- Industrial
- Documents
- 3
- Languages
- EN · ZH
- Last added
- 2000-01-01
Start here
Siemens Low Pressure Control Products System Manual
The document lists Siemens low‑pressure control equipment, including circuit‑breakers up to 63 A, various contactor combinations and overload relays. Technical tables give current and voltage ratings for the 3VU13 and 3VU16 product families.
Tables on pages 4‑6 show the rated currents (e.g., 0.1‑25 A for 3VU13) and voltage ranges for each model, allowing engineers to select the appropriate device for their applications.
Siemens 3VU16 specifications
| 3VU13 current rating | 0.1~25A |
|---|---|
| 3VU16 current rating | 1~63A |
| 3VU13 voltage rating | 63A |
| 3VU16 voltage rating | 63A |
All Siemens 3VU16 documents by type
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What is the current rating of the 3VU13 model?
The 3VU13 model is rated for a current range of 0.1 to 25 A.
What is the current rating range for the 3VU13 model?
The 3VU13 model is rated for currents from 0.1 A up to 25 A.
From: Siemens 3VU13/3VU16 Low Pressure Control System Service Manual
How can I obtain technical support for this Siemens product?
Contact Siemens support via email [email protected] or visit the support site viiw.ad.siemens.com.cn/service.
From: Siemens 3VU13/3VU16 Low Pressure Control System Service Manual
What is the maximum rated current for the 3VU13 circuit‑breaker?
The 3VU13 circuit‑breaker is rated up to 25 A.
From: Siemens 3VU13/3VU16/3VF1 Circuit Breaker Product Leaflet
Do the 3VU16 and 3VF1 circuit‑breakers include overload releases?
The 3VU16 and 3VF1 used in starter combinations have only instantaneous short‑circuit releases and no overload releases.
From: Siemens 3VU13/3VU16/3VF1 Circuit Breaker Product Leaflet
