Key facts
- Brand
- Siemens
- Model
- TP 170micro
- Industry
- Industrial
- Documents
- 3
- Languages
- EN · ZH
- Last added
- 2000-01-01
Start here
Siemens SIMATIC TP 170micro, TP 170A, TP 170B, OP 170B HMI Operating Instructions
The operating instructions are intended for users, commissioning engineers, service technicians, and maintenance personnel who work with the SIMATIC TP 170micro, TP 170A, TP 170B and OP 170B HMI devices. It covers safety information, planning, installation, connection, operator controls, system configuration, project preparation, execution, and service procedures.
Key sections include safety warnings, installation guidelines, wiring diagrams, communication setup with SIMATIC PLCs, WinCC flexible configuration, backup and restore of projects, and detailed maintenance tasks. The manual also provides an appendix with abbreviations, a glossary, and reference tables for alarm and screen capacities. This manual is written in Chinese.
Siemens TP 170micro specifications
| Display resolution | 640 × 480 pixels |
|---|---|
| CPU | RISC CPU |
| Flash storage | 5 Mbyte |
| Dimensions (MP 270B) | 212 mm × 156 mm |
Source: Siemens SIMATIC HMI Multi Panels MP 270B, MP 370, OP 77B, TP 170micro User Manual
All Siemens TP 170micro documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What does the warning triangle symbol indicate in the safety section?
The warning triangle marks a safety warning that, if ignored, could cause death or serious personal injury.
From: Siemens SIMATIC TP 170micro, TP 170A, TP 170B, OP 170B HMI Operating Instructions
How many variables can be defined on a TP 170A device?
A TP 170A can hold up to 500 variables.
From: Siemens SIMATIC TP 170micro, TP 170A, TP 170B, OP 170B HMI Operating Instructions
What is the maximum number of discrete alarms for TP 170micro?
The TP 170micro can handle up to 500 discrete alarms.
From: Siemens TP 170micro TP 170A TP 170B OP 170B Operating Guide
How many characters are allowed per alarm text line?
Each alarm text line may contain up to 80 characters.
From: Siemens TP 170micro TP 170A TP 170B OP 170B Operating Guide
