Siemens MAG 8000 Flow Meter User Manual
User Manual 51 pages · 6.9 MB · ZH
The MAG 8000 is an electromagnetic flow meter designed for water and other conductive liquids, offering high accuracy and a wide measurement range. It complies with IP68/NEMA 6P protection and supports pipe sizes from DN 25 up to DN 1200.
This manual covers product overview, installation steps, commissioning procedures, parameter configuration, troubleshooting, and maintenance guidelines, including wiring diagrams, cable specifications, and safety information. This manual is written in Chinese.
Siemens MAG 8000 specifications
| Maximum flow velocity | 3 m/s (10 ft/s) |
|---|---|
| Pipe size range | DN 25 – DN 1200 |
| IP rating | IP68/NEMA 6P |
| Cable length (max) | 300 mm (12 inches) |
| Pressure rating | 2.9 mbar (0.04 psi) |
All Siemens MAG 8000 documents by type
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum flow velocity the MAG 8000 can measure?
The device can measure flow velocities up to 3 m/s (10 ft/s).
What IP protection does the MAG 8000 have?
It is rated IP68/NEMA 6P for dust and water protection.
